System-on-Modules
Explore AMD Kria Kria K26 System-on-Module
PN: SM-K26-XCL2GC
Price: $325.00 USD
Lead Time: 26 weeks
SYNCED FROM AMD.COM · 2026-10-14
Overview
The newest path to whole application acceleration, the K26 SOM is optimized for edge vision applications requiring flexibility to adapt to changing requirements. Available in Commercial and Industrial Grade variants for production deployment.
Device Support: Zynq UltraScale+ MPSoC
Specifications
| Designed to Enable Smart City and Smart Factory Applications | 3X vision AI performance and 2X performance-per-watt versus competing SOMs 1 1 See WP529 Native ROS 2 support for 5X productivity for robotics and industrial automation |
| Out-of-the-Box Hardware Acceleration | Leverage pre-built accelerated applications without needing FPGA place-and-route Tailor AI models and application code to your requirements |
| Production Qualified and Certified Commercial and Industrial Grades | Commercial: operating range 0 to 85°C for smart camera, embedded vision, tracking & identification Industrial: operation range -40-100°C and ruggedized for extreme environments |
| Dimensions (with heat spreader) | 77 mm x 60 mm x 11 mm |
| Application Processor | Quad-core Arm® Cortex®-A53 MPCore™ up to 1.5 GHz |
| Real-Time Processor | Dual-core Arm Cortex-R5F MPCore up to 600 MHz |
| Graphics Processing Unit | Mali™-400 MP2 up to 667 MHz |
| Video Codec Unit (VCU) | 1 - up to 32 streams (total resolution ≤ 4Kp60) |
| Trusted Platform Module (TPM) | Infineon 2.0 |
| Memory On-Chip* | 26.6 Mb On-Chip SRAM |
| Memory On-SOM | 4GB 64-bit DDR4 (non-ECC) and 16 GB eMMC |
| High-Speed PS Connectivity (GTR) | PCIe® Gen2 x4, 2x USB3.0, SATA 3.1, DisplayPort™, 4x Tri-mode Gigabit Ethernet |
| General PS Connectivity (MIO) | 2xUSB 2.0, 2x SD/SDIO, 2x UART, 2x CAN 2.0B, 2x I2C, 2x SPI, 4x 32b GPIO |
| GTH 12.5 Gb/s Transceivers | 4 (PCIe Gen3 x4, SLVS-EC, HDMI 2.0, DisplayPort 1.4) |
| GTR 6 Gb/s Transceivers | 4 |
| PS MIO (1.8V) | 49 |
| PL High-density (HD) I/O (3.3V) | 69 |
| PL High-performance (HP) I/O (1.8V) | 116 |
| System Logic Cells (K) | 256 |
| DSP Slices | 1,248 |
| Typical Power | 7.5W |
| Maximum Power | 15W |
| Thermal Interface | Passive (Heat spreader) |
| Commerical Speed & Temp Grade | -2 speed grade, low voltage and 0 to 85°C temperature range |
| Industrial Speed & Temp Grade | -2 speed grade, low voltage and –40 to 100°C temperature range |
